Systems Modeling Training in Zagreb

This training will teach you how to use SysML, the modeling language for systems engineering. In particular, you will learn about block diagrams for structural modeling of complex systems. You will deepen the sequence diagram, state diagram and activity diagram for dynamic modeling.

You will also learn how to use specific SysML diagrams such as the requirements diagram and the parametric diagram, as well as the concept of allocation. We will also emphasize the need to define a modeling approach, adapted to the business context and the type of system to be studied.

The practice will be done using the Cameo Systems Modeler (MagicDraw) modeling tool from NoMagic.

Teaching method

• Theoretical presentation illustrated with examples
• 50% practical work with Cameo Systems Modeler on a case study throughout the training

Domain Driven Design (DDD) is an approach for handling complex behaviors when developing software.

This Introduction to Enterprise Architect training course is designed for all persons who wish to use Sparx Systems’ UML modelling tool, Enterprise Architect, for their modelling activities yet are unfamiliar with the features, functions and use of Enterprise Architect.

Using a combination of lectures, demos, and interactive labs, this course showcases the foundations for building and maintaining an Enterprise Architecture (EA) utilizing the Unified Architecture Framework (UAF) version 1.2.

The OCSMP Model Builder – Fundamental examination tests knowledge and skills required to construct a basic SysML model of a system. The examination covers model concepts and organization, basic requirements capture and management, structure and behavior models, parametric models, allocation relationships, and use of stereotypes. Using the knowledge and skills covered at this level plus familiarity with a suitable SysML modeling tool, a holder of the OCSMP Model Builder – Fundamental Certification should be a productive contributor to modeling tasks performed by a Systems Engineering team employing a model-based systems engineering approach using SysML.  The OCSMP Model Builder – Fundamental Certification is a prerequisite for the program’s two higher levels, and requires the OCSMP Model User Certification as its prerequisite.

This examination (as well as the others in the OCSMP series) tests your ability to apply the knowledge and skills listed here in the context of a model of a system. As you study, go beyond each individual diagram to understand how aspects that it models can influence or affect aspects of the system represented in other diagram types.

In this instructor-led, live training in Zagreb (online or onsite), participants will learn how to use SysML as implemented in Enterprise Architect (EA) to carry out system requirements analysis and modeling.

By the end of this training, participants will be able to:

• Understand and apply SysML to Systems Engineering projects, using a Model Based Systems Engineering (MBSE) approach.
• Identify system requirements based on use case models.
• Design and analyze system architecture.

This practical training will show you how to use efficiently the SysML modeling language. You will discover in particular the block diagrams for structural modeling of complex systems. You will deepen the sequence diagram, the state diagram and activity diagram for dynamic modeling. You will also learn to use specific SysML diagrams, such as the requirements diagram and the parametric diagram, as well as the important concept of allocation. We will also focus on the need to define a modeling approach, adapted to the context of the company and the type of system to be studied. We will finally see what is the state of the art of SysML modeling tools.

Audience:

Project managers, architects, system engineers, having to model complex systems including both software and hardware

Teaching Method:

• Theoretical presentation with examples
• Case Study on paper (demo of a SysML tool by the trainer)

The course is designed for analysts, designers, developers, testers and project managers.

The workshop presents a problem analysis, design and documentation systems using UML and Enterprise Architect of Sparx Systems. During the training will be presented to the advanced capabilities of the program (such as MDA, profiles, XMI), and best practices that can greatly simplify and accelerate modeling.

Because the training focuses on the Enterprise Architect tool it is required for participants to already know how to model in UML. For those who would like to learn modeling we have dedicated training for UML.

The training method

Lecture 10%, 90% workshop

This course is designed for business analysts, managers, team leads and process owners to provide them with the required competencies for creating use case diagrams and use case scenarios, which serve as a vehicle for eliciting, analyzing, documenting and communicating functional requirements. Delegates will practice creating use cases in the Unified Modeling Language (UML) to graphically represent the interactions between use cases and actors.
